gridofrings

I really wanted a Tocante Karper by Ciat Lonbarde, but was never able to find one, and at the same time was slightly put off by the scales available. It occurred to me that Duncan Geere’s gridofpoints may be the perfect thing to adapt to create a version of the Karper that suited my needs. Thank you again to Duncan for his support and permission to adapt this.

Play Mutable Instruments’ Rings via a quantised keyboard on your grid.

• e2: change root note
• e3: change scale
• k2: up a fifth
• k3: down a fifth

grid (required)

• press a key to make beautiful sounds
• left/right position controls pitch
• up/down position controls timbre / midi CC
• top row lets you save and load root/scale combinations
• long press to save, short press to load

crow (optional)

• out1: v/oct
• out2: gate
• out3: -5V to 5V on up/down axis
• out4: 0 to 10V on up/down axis

install

Find it in the Maiden project manager

troubleshooting

If you get an ‘error: init’ on load, then make sure you have a Grid plugged in. The script doesn’t function without one. If you have a Grid plugged in and you’re still seeing this error then post below with details of what Grid you’re using and how it’s connected to your Norns.

version history

v1.1

Added access to the engine params in the menu

v1.0

Initial release
